COMANT COMDAT ANTENNA (CI-2480-216)

Part #: CI-2480-216
Comant
Availability: In Stock

CI2480216

$1,293.60

compare

Overview

Frequency • 2332.5 – 2345.0 MHz XM® 118-137 MHz VHF

The CI 2480-216 is the first ComDat to provide VHF and XM® Weather Data in a single, combined antenna. Patented design offers XM® approved performance for popular WX system form Garmin® and Avidyne®.

Built-in 80 dB low pass filter protects both GPS and XM® antennas against unwanted VHF interference.

Helicopter rated, this model has been tested the toughest RTCA DO-160D environmental conditions.

Part: CI-2480-216 Categories: , , , Tag:
Weight 2 lbs
Brands

Specifications

  • Frequency: 118-137MHz
  • VSWR: 2.5:1 Maximum
  • Polarization: Vertical
  • Radiation Patter: Omnidirectional
  • Impedence: 50 Ohms
  • Power Rating 50 Watts
  • Gain – Active: 30-34 dB
  • DC Voltage: 4 to 24 VCD
  • DC Current: 25 mA (Minmum) / 55 mA (Maximum)
  • Noise Figure: 2.7 dB (Maximum
  • Out of Band Filter Attenuation: 25 dB Minimum
  • Aircraft Type: Single Engine Only
  • RTCA Environmental Testing: DO-160D
  • FAA TSO: C37d,C38d
